Whelen 9 Function High Current Power Control Switch

Whelen

$319.00

Quantity

The Whelen 9 Function High Current Power Control offers the ability to control many high current loads from one convenient switch box. Six programmable push-button switches and one programmable three position slide switch controls nine total 20 amp fused circuits using built-in relays. Connects to most lightbars that use standard switching, and auxiliary warning equipment without the use of separately mounted relays or relay boxes.

Features:
  • Control 9 lightbar functions or other auxiliary equipment.
  • Front panel programmable slide switch with three 20 amp relays.
  • Six front panel programmable push-button momentary type switches with 20 amp relays.
  • All switches can be programmed to activate any combination of the relay outputs, or any other momentary push-button switch.
  • The 6 momentary switches can be easily programed for one of four operations, push-on push-off, momentary, flashing or timed output.
  • Easy reset to factory default.
  • Clone one controller to another.
  • Any switch can be programmed for siren activation.
  • Auxiliary input slide switch, position 3.
  • Momentary contact for low power, trunk lock or gun lock control.
  • Long lasting solid-state green LED backlighting makes it easy to read the translucent legend buttons at night.
  • Active switches are easily identified in bright sunlight or at night by a red indicator located just below each button.
  • 72 press-on legend tabs.
  • Individual 20 amp fused outputs.
  • Designed to stack-mount with the WS295 Series Siren amplifiers or Traffic Advisor Control Head.
  • Includes a universal bail bracket strap mounting kit for over or under dash mounting.
  • Dimensions: 6.125" W x 1.5625" H x 6.25" D.
  • Weight: 1.75 lbs. (0.8kg).

Click HERE For Product Manual

Click HERE For Installation Manual

SKU: PCCS9RW
