Whelen M6 Linear Super-LED Lighthead

Whelen

$229.00

Lens Colour
Led Colour
Flash Or Steady Burn
Quantity

The Whelen M6 Linear Super-LED Lighthead is a mid-sized member of the M Series family of lightheads. The M Series is the only Patented Linear-LED lightheads with a bold look to the future in fire, ambulance and rescue truck emergency lighting. Designed to stand-up to the harsh environments and standards of the industry while providing top of the line performance!




Features:

  • Surface mounted via two screws.
  • Super-LEDs provide unmatched high intensity warning, low current consumption.
  • Unique lens shape is completely illuminated with patented Linear-LED designed reflector assembly.
  • Lens and reflector are a sealed assembly.
  • Available with color (same as LEDs) or clear lens.
  • Mounting screws are located outside of the sealed lens/reflector assembly eliminating water infiltration.
  • Replaceable light engine is accessed from the rear of the lens/reflector assembly.
  • Rear gasket ensures that the lighthead and optional flange does not touch the vehicle's surface.
  • Updated design allows for faster and easier installation.
  • M6 lightheads have 164 Scan-Lock flash patterns.
  • Choose from Solid, Left/Right, Top/Bottom, In/Out, or Diagonal sequencing.
  • Meets KKK 1822F, NFPA 1901, SAE and EC65 specifications.
  • 82 flash patterns meet California Title XIII compliant.
  • Hi/Low intensity function included (Violet wire).
  • Hard coating on lens resists scratches, chemical and corrosive damage.
  • Current Draw @ 12.8 VDC: 2.25 (Peak*), 0.9 (Average). * in steady on mode
  • Dimensions (approximate): 4-5/16" (109mm) H x 6-3/4" (170mm) W x 1-3/8" (35mm) D.

Whelen 5 Year Warranty

Click Here For Product Brochure

Click Here For Installation Guide

SKU: M6C24
