Whelen LIN3 Linear Super-LED Lighthead
The Linear3 (LIN3) Super-LED Lighthead is based on Whelen's highly popular TIR3. The LIN3 uses 3 Generation III LEDs and the same Linear Optics technology used in Whelen's Avenger Series. The LIN3 is very much like the TIR3 in feature set and specifications. In Standard Mode the LIN3 has 10 Scan-Lock Flash Patterns plus Steady Burn. In Synchronized Mode the LIN3 has 7 Scan-Lock Flash Patterns each with Phase 1 and Phase 2. All LIN3s come with clear outer lenses, colored LEDs and the New Deeper Style Black ABS Flange.
- 3 Generation III LEDs with Linear Optics.
- Standard Mode: 10 Scan-Lock Flash Patterns plus Steady Burn.
- Synchronized Mode: 7 Scan-Lock Flash Patterns each with Phase 1 and Phase 2.
- Four Wire Synchronizable Version.
- Fully encapsulated for vibration, moisture and corrosion resistance.
- Black Surface Mount Flange Included Standard.
- Designed for Horizontal Mounting.
- Voltage: 12 VDC.
- Amp draw: 390mA @ 13.6 VDC
- Dimensions: 3-5/8" W x 1-5/16" H x 1-5/16" D.
Whelen Five Year Warranty
