Whelen Legacy Series Slim Lightbar

Whelen



Due to the amount of variants and customisation that is possible with Whelen lightbars we limit our online selection to a basic variety. For custom lightbar orders including DUO & TRIO LED modules please email: sales@emergenz.nz , We will be more than happy to assist.


Reminiscent of the original Freedom Series, the Legacy Series features LEDs of outstanding quality and comes with new, additional functionalities to maximise performance and reliability. A Legacy lightbar provides that boost of confidence and peace of mind that only equipment of the highest standard can offer.


Features

  • Height without mounting feet is only 1-5/8” (41.27mm).
  • New Diamond Optix™ linear reflector optic design.
  • Newly designed, high-output linear combo “Multi-Angled” corner modules produce light straight out and to the side. These modules cover the critical 45° angles. The four combo modules produce 360° warning signal.
  • Whelen®’s exclusive Collimator™ patented design captures, collects and focuses light for unbeaten light output. Optional Traffic Advisor™ in single or DUO™ colour.
  • Advanced Thermal Design “ATD” provides attention-demanding new flash patterns for more lighting on-time. These include SteadyFlash™ for use at night-time traffic stop/accident scene for added protection for officers. ATD reduces the stress on the LEDs themselves, when the dwell time of the LEDs is extended.
  • One piece UNI-DOME construction with a single sealing point. Each dome slides onto the aluminium extrusion and wraps around all internal components while the wiper seal protects your lightbar from the worst elements.
  • Metal top shield stays cool to the touch, protects the lightbar from nature’s elements such as hail and provides passive solar radiation to direct heat away from internal components to ensure long life and reliability.
  • Centre divider(s) with LIM (Liquid Injection Molded) wiper seals ensure lightbar integrity in all conditions.
  • Legacy “plug and play” into the CenCom Sapphire™ controller. A WeCan® controller module is supplied for use with other switch centres.
  • Hard-coated lenses shrug off environmental damage from the sun, salt and road chemicals.
  • Optional corner, long and short module colour filters. Available in Red, Blue or Amber.
  • The I/O board snaps into brackets, and point to point wiring between each lighthead and the I/O board creates a clean look and allows for easy serviceability.

Legacy SOLO Features:

  • Single colour Super-LED® modules in new reflector assemblies.
  • WeCan® programmable.
  • Whelen®’s exclusive Collimator™ patented design captures, collects and focuses light for unbeaten light output.
  • Optional take-downs are available in 3 or 6 diode TIR LED modules with 15° adjustment.
  • Optional alley lights are available in a 3 diode module that is 15° adjustable.
  • Optional photocell to automatically dim at night and still meet SAE Class1 requirements in low power mode.

Legacy DUO Features:

  • Optional take-downs are available in 3-LED or 6-LED modules.
  • Optional alley or DUO+ integrated alley and warning light module ensures 360° of contiguous light, no dead spots and no gaps.
  • Only DUO+ lets you operate the alley and the warning lights at the same time, at full intensity.
  • DUO+™ technology and Advanced Thermal Design “ATD” provide attention-demanding new flash patterns for more lighting on-time. These include “SteadyFlash™” for use at night-time traffic stop/accident scene for added protection for officers. ATD reduces the stress on the LEDs themselves, when the dwell time of the LEDs is extended.
  • Aluminium top shield stays cool to the touch, protects the lightbar from nature’s elements such as hail and provides passive solar radiation to direct heat away from internal components to ensure long life and reliability.
  • Hard-coated lenses shrug off environmental UV damage from the sun, salt and road chemicals.
  • Optional corner, long and short module colour filters. Available in Red, Blue or Amber.
  • Legacy™ DUO ™is the first lightbar with a photocell to automatically dim at night.


Five year HDP® Heavy-Duty Professional warranty on all Whelen Legacy Series lightbars.


Click Here For Product Brochure

Click Here For Installation Guide
