Whelen CenCom Core



or 4 interest free payments of $399.50 withlearn more

Featuring the greatest configurability, speed, and expansion yet, CenCom Core™ is a system created to enhance officer safety with advanced automation and remote connectivity.

  • All-new design allows for access to every connector and fuse from the top of the box
  • WeCanX™, our newest CAN-based communication system provides true system synchronization, greater speed capabilities, expanded peripheral add-ons, and full support of diagnostics
  • Vehicle-to-Vehicle Sync automatically synchronized lights and tones on multiple vehicles
  • Dynamic Variable Intensity™ patterns gradually increase or decrease the output intensity for nighttime emergency scenes
  • Advanced Customization with support of 99 WeCanX devices, allowing you to customize Core in ways never before possible in a control system
  • Supports remote firmware updates via USB-C with Whelen Command™, our newest programming software

SoftwareWhelen Command™
HardwareUp to 99 WeCanX devices
Outputs2 15A outputs
4 10A outputs
16 2A outputs
1 dry contact relay
23 total outputs Flashing outputs
Every output across the system can be synchronized
Inputs12 logic inputs
1 ignition power-up input
4 analog inputs
17 total inputs
Connections1 ethernet connection
1 WeCanX connection
2 CANport™
1 USB-A host
1 Micro SD card slot
99 remote modules
SensorsBattery voltage sensor
Temperature sensor
3 axis accelerometer sensor
DVIGradually increase or decrease the output intensity within a flash pattern or tone
Tone SyncSync amplifiers and speakers together
Sync tones with lights (Patent-Pending)
DiagnosticsHas diagnostic indicator
Expansion ModulesLightbars, Inner Edge™ FST™ and RST™, External Amplifier, External Howler Siren, Remote 8 or 16 Output Expansion Module, Control Point and Input Expansion Module, Traffic Advisor™ Module, V2V Sync Module
CertificationsMeets all applicable SAE and California Title XIII requirements with various Whelen speakers
WarrantyFive year warranty

SKU: 10001
