Whelen 8 Function Power Control Center

Whelen

$389.00

Quantity

The Whelen 8 Function Power Control Center (PCC8R) has a basic, eight position keypad with remote relay box, ideal for Construction, Tow and Wrecker vehicles. The LED backlit membrane switches are designed with a solid rubber overlay for moisture resistance. Each switch is programmable for push-on/push-off or momentary activation. This eight function control center comes with three 20 amp relays and five 10 amp relays.

Features:
  • Straightforward controls - one switch controls one relay.
  • Diagnostic feedback for relay confirmation.
  • Programmable for push-on/push-off or momentary activation.
  • LED backlit membrane switches are designed with a solid rubber overlay for moisture resistance.
  • 12 VDC or isolated switching.
  • Ignition control available via DIP switch.
  • Three 20 amp relays and five 10 amp relays.
  • 70 amps maximum load.
  • Dimensions of Relay Box: 7 1/4" L x 4 3/4" W x 1 1/4" H.
  • Dimensions of Controller: 4" W x 2 5/8" T x 13/16" D.
  • Whelen Two Year Warranty

Click Here For Installation Guide

SKU: PCC8R
