Whelen 4 Function Lighted Switchbox

Heavy Duty Power Control Center and Switch Panels

Features:

• Compact Design
• Rocker style single pole/single throw switches, rated at 25 amps peak, with ‘active' LED indicators that light up to indicate function in use
• Individual spade-type fuses conveniently located on rear mounted fuse strip.
• Ignition controlled back lighted legend windows for easy visibility in any light
• Back light circuit can be connected to vehicle dimmer switch to control backlight intensity
• 72 commonly used press-on switch function label legend tabs standard
• Black epoxy-finished, steel housing
• Common ground post for ease of installing
• 12 VDC

PCC4W only

• Four 25 amp switches
• Flying leads connection
• Includes an adjustable 2 position universal bail bracket strap mounting kit for over or under dash mounting
• Adjustable bail bracket overall heights: 2-3/4" (70mm) H (lower bracket position), 3-1/4" (83mm) H (higher bracket position)
