Whelen Eight Linear 6 LED Traffic Advisor & Control Head

Whelen

$1,179.00

LED Modules
End Flashing LEDs
Quantity

The Whelen Eight Lamp Linear 6 LED Traffic Advisor (TANF85) comes with eight front loading 500 Series Linear Super-LED modules for and intensely bright warning signal. This Traffic Advisor come complete with a Whelen LED Traffic Advisor Control Head (TACTL5) for complete control of all signal functions. Traffic Advisors are the most versatile answer to alert oncoming traffic with a bright visual sequencing signal warning about correct traffic flow direction. Professional, emergency and special use vehicles can be fitted with models for rear window deck or be mounted to the exterior of the vehicle.

TANF85 Features:

  • 8 front loading 500 Series Linear Super-LED modules for and intensely bright warning signal.
  • High intensity Super-LEDs are rated for over 100,000 hours of service with low current consumption.
  • Rugged, water resistant LED modules stand up to road shock and vibration.
  • 4 programmable direction sequence modes, up to 8 Scan-Lock flash patterns.
  • Black rectangular extruded aluminum housing.
  • Size: 2-3/8" (60mm) H x 2-3/8" (60mm) W x 45-1/8" (115cm) L.
  • Mounting Bracket, for top of Vehicle (Horizontal) Mounting Available

TACTL5 Features:

  • Hi/Low Light Intensity Settings.
  • Four Position Operating Mode Switch (Left, Right, Split and Flash).
  • Front Panel LED Display Replicates Actual TA Pattern.
  • AUX On/Off switch that allows the operator to activate a remote device (10 Amp max).
  • Size: 2" H x 6" W x 3.5" D.

Left, Right and Split Mode Patterns:

  • Sequence Triple Flash
  • Double Sweep
  • Sequence On Double Sweep
  • Sequence On/Sequence Off

Flash Mode Patterns:

  • ModuFlash
  • ActionFlash

Click Here For TACTL5 Installation Guide

Click Here For TANF65/85 Installation Guide
