Whelen 6 Function Lighted Switchbox

Whelen

$189.00

Choose Your Model
Quantity

Switch Box with Six 25 AMP SPST Switches, Lighted

Features:
  • Compact Design
  • Rocker style single pole/single throw switches, rated at 25 amps peak, with ‘active' LED indicators that light up to indicate function in use
  • Individual spade-type fuses conveniently located on rear mounted fuse strip
  • Ignition controlled back lighted legend windows for easy visibility in any light
  • Back light circuit can be connected to vehicle dimmer switch to control backlight intensity
  • 72 commonly used press-on switch function label legend tabs standard
  • Black epoxy-finished, steel housing
  • Common ground post for ease of installing
  • 12 VDC 6"L x 3 9/16"W x 2 1/4" H
PCC6W
  • PCC6W has six 25 amp switches
  • PCC6W has "piano style" backs with rear mounted "captive" terminal block for easy installations
  • Aftermarket console mounting recommended but includes an adjustable 2 position universal bail bracket strap mounting kit for over or under dash mounting
  • Adjustable bracket overall heights: 3-3/8" (86mm) H (lower bracket position), 3-3/4" (96mm) H (higher bracket position)
PCC6W1
  • Similar to PCC6W, Except Last On/Off Switch is Replaced with a Momentary Switch

Click Here For Product Brochure

Click Here For PCC6W Installation Guide

Click Here For PCC6W1 Installation Guide

SKU: PCC6W1
