Whelen 10 Function Lighted Switchbox

Switch Box with Ten 25 AMP SPST Switches, Lighted

Features

• Compact Design
• Rocker style single pole/single throw switches, rated at 25 amps peak, with ‘active' LED indicators that light up to indicate function in use
• Individual spade-type fuses conveniently located on rear mounted fuse strip
• Ignition controlled back lighted legend windows for easy visibility in any light
• Back light circuit can be connected to vehicle dimmer switch to control backlight intensity
• 72 commonly used press-on switch function label legend tabs standard
• Black epoxy-finished, steel housing
• Common ground post for ease of installing
• 12 VDC
• 6"L x 3 9/16"W x 2 1/4" H

PCC10W

• PCC10W has ten 25 amp switches
• PCC10W has "piano style" backs with rear mounted "captive" terminal block for easy installations
• Aftermarket console mounting recommended but includes an adjustable 2 position universal bail bracket strap mounting kit for over or under dash mounting
• Adjustable bracket overall heights: 3-3/8" (86mm) H (lower bracket position), 3-3/4" (96mm) H (higher bracket position)

PCC10W1

• Similar to PCC10W, Except Last On/Off Switch is Replaced with a Momentary Switch
